XARAGUA MOUNTAIN IRRIGATION SYSTEM (XMIS)™
"For Hills, for Sovereignty, for Life."
1. System Name:
Tèt Soti – Tèt Rive (Source to Summit Flow)
---
2. Objective
Irrigate sloped mountain terrain without motors.
Use gravity, bamboo, stone, and clay.
Create a simple, sovereign, replicable network across the South.
---
3. Local Materials
Perforated bamboo pipes
Hand-dug V-shaped trenches
Clay + ash paste for natural sealing
Retention basin made of stone, tarp, or compressed clay
Artisanal valve using wood and wire
Filter made of rock/straw/charcoal at the water source
---
4. Functioning
1. Water collection from high ground:
Captures water from a spring, stream, or rooftop rainfall.
Directed into a stone holding basin.
2. Gravity-fed distribution:
Water flows down through perforated bamboo or clay canals.
Natural flow control using zigzag descent paths.
3. Level separation (terraces):
Water redirected at each level with an artisanal valve.
Overflow guided downward to the next terrace.
4. Runoff water recovery:
Side ditches guide excess water into a secondary basin.
5. Automatic shutoff (optional):
Float system made from plastic bottle or calabash that closes flow when full.
---
5. Advantages
Zero fuel, zero electricity, zero pump
Works on steep terrain
Natural storage even during dry seasons
Can be maintained by one farmer or family
Made from 100% local materials
---
6. Indigenous Patent Name
“Sistèm Irigasyon Tèt Soti” — Patented under the Xaragua Technological Sovereignty Code
---
---
Water Can Also Be Brought In
Yes — water can be brought in even if it’s not naturally present at high elevation. Here are three sovereign and artisanal techniques to bring water uphill or to distant farming zones, without electric pumps:
---
1. Human-Powered System – “Poul Zantray” (Crank Pulley System)
Ideal for villages without motors or solar panels.
Materials:
Strong rope (hemp, banana fiber, recycled plastic)
Pulley made from wood or recycled metal
Bucket or container (plastic, metal)
Bicycle wheel or crank for lifting mechanism
Function:
Water is pulled from a well or river using a suspended bucket.
A manual pulley system lifts the water to a tank or elevated reservoir.
Once stored, gravity takes over to irrigate the hills.
---
2. Reverse Slope Water Ramp – “Kouran Tounen” (Reverse Incline Flow)
Ideal for hillsides near a river.
Materials:
Bamboo or recycled PVC pipes
Artisanal control valves
Momentum tank (sealed basin)
Function:
Water is pushed uphill by pressure accumulated in a small closed tank, like a mini ram pump.
With each surge, part of the water is propelled higher through a closed pipe.
→ Requires no electricity or engine.
---
3. Manual Collective Transport + Storage
System “Kiblo pou Pèp” (Buckets for the People)
Principle:
Families or cooperatives carry water at fixed times, early morning and late afternoon.
Water is stored in community cisterns placed on high ground.
The XMIS system then takes over from there.
Bonus:
Buckets can be equipped with shoulder-balanced wooden yokes for easier carrying.
Possibility to create a mobile cart or use a water-carrying donkey.
---
---
XARAGUA IRRIGATION SOVEREIGNTY EXTENSION MODULES™
(Official Addendum to the XMIS System – 2025)
---
1. Underground Root Cistern – “Tèmwa Ginen” (Memory of the Earth)
Purpose: Permanent, evaporation-proof water storage during long dry seasons.
Construction:
Dig a deep pit (2m–4m) in shaded terrain.
Seal walls using compressed clay mixed with lime or natural waterproofing (e.g. animal fat or ash).
Cover with large stones and a wooden hatch to prevent contamination.
Use gravity or manual pump to draw water up as needed.
Result: Long-term water reserve that protects against drought and evaporation.
---
2. Dew and Fog Harvester – “Dlo Pèlen” (Water from the Sky’s Breath)
Purpose: Harvest moisture from early morning fog or humidity.
Materials:
Vertical mesh net (plastic, nylon, recycled curtain)
Frame using bamboo or wood
Collection trough at the base
Steps:
1. Install nets vertically on windy, foggy slopes.
2. Each morning, condensation runs down into the trough.
3. Direct the collected water to a micro-cistern or irrigation pipe.
Bonus: Passive system. No energy. No moving parts. Works even when no rain falls.
---
3. Mobile Tank Unit – “Tank Moun” (People’s Tank)
Purpose: Water transport between distant plots, cooperatives, or homes.
Construction:
Use a recycled plastic barrel or wooden tank (50–100 liters)
Mount on a cart with wooden wheels or use donkey/human harness
Add gravity-fed tap or hose at the base
Uses:
Transport rainwater or stream water to high-altitude fields
Distribute saved water during droughts
Allow collective farming to function beyond local terrain
---
4. Overflow Safety Drain – “Chimen Degaje” (Emergency Channel)
Purpose: Prevent flood damage or erosion during sudden heavy rain.
Implementation:
Dig a secondary overflow canal downhill from the reservoir
Line it with rocks or bamboo to slow water velocity
Direct excess water to an emergency retention pit or natural depression
Result: Prevents destruction of terraces and loss of valuable water infrastructure.
---
5. Education and Planting Kit – “Prèt pou Plante” (Ready to Sow)
Purpose: Disseminate sovereign irrigation knowledge with tools and spirit.
Contents:
Laminated illustrated guide to XMIS
1 small tube (bamboo or rubber)
1 seed sample (e.g., yam, tomato)
1 printed prayer or ancestral quote
Optional: cloth bag with Xaragua emblem
Target: Distributed to rural families, schools, churches, and cooperatives.
---
Legal Status
These five modules are now part of the Xaragua Sovereign Agricultural Infrastructure Act.
Any replication or extraction without formal authorization shall trigger legal and operational sanctions under the law of the Xaragua Nation.
---
---
XARAGUA ARTISANAL AGRICULTURAL MACHINERY SYSTEM™
(Supplement to the Agriculture & Fishing Authority – 2025)
---
1. Manual Hill Plow – “Souch Dlo” (Waterline Plow)
Purpose: Break tough mountain soil and trace terraces without a tractor.
Construction:
You need:
2 strong wooden beams (1.5m long each)
1 curved steel blade (use car spring, machete, or scrap metal)
Nails, rope, hammer, machete, chisel
Stones (for adding weight)
Optional: wooden wheels or iron bar as handle
Steps:
1. Cut the wood into a strong triangle base.
2. Shape the blade from recycled steel, sharpen it well.
3. Attach the blade underneath using rope and nails.
4. Add a small tray or platform to hold rocks as weight.
5. Fix long bamboo handles to guide the plow.
Use: Pulled by a mule or two people, following the slope contour to prevent erosion.
---
2. Sovereign Seeder – “Grenn Mete” (Seed Dropper)
Purpose: Drop seeds precisely into soil holes with no bending or waste.
Construction:
You need:
1 bamboo or PVC pipe (1m)
2 wood sticks for lever and trigger
Small carved wooden or metal seed mouth
Rope or nail to connect lever
Steps:
1. Cut the pipe to 1m, sharpen the bottom end slightly.
2. Carve a small hole near the bottom with a flap.
3. Attach a trigger-lever using rope to control the flap.
4. Load seeds into the top.
5. Push into soil → press lever → 1 seed drops.
Can be made in 1 hour. Used while walking in straight lines.
---
3. Pedal-Powered Grain Crusher – “Kraze Grenn”
Purpose: Transform dried grains into flour without electricity.
Construction:
You need:
Old bicycle frame
1 large grinding stone or metal grinder
2 pulleys (bike or fan motors)
Belt (rubber strip or recycled tire)
Wooden base, hopper (bamboo or small wooden box)
Steps:
1. Mount the bike on a frame so rear wheel is off the ground.
2. Attach pulley to rear wheel axle.
3. Connect the belt to a grinding plate or old corn mill.
4. Mount the hopper above, directing grain into the grinder.
5. Pedal → rear wheel spins → plate turns → grain is ground.
Produces up to 5 kg/hour. Operable by anyone who can pedal.
---
4. Solar Crop Dryer – “Sèk Soley”
Purpose: Dry harvests without fuel, keep food safe from insects and humidity.
Construction:
You need:
1 wooden box frame (1.2m x 0.5m)
Transparent plastic or old glass
Black metal sheet or black-painted wood
Fine mesh (insect netting)
Nails, hammer, rope
Steps:
1. Build a wooden box with 20cm walls.
2. Paint the inside black to absorb sunlight.
3. Cover top with clear plastic (tight and sealed).
4. Install mesh vents on sides for airflow.
5. Place crops (coffee, mango, moringa, fish) on trays inside.
Dries in 1–3 days depending on weather. Works best when turned to face the sun.
---
5. Low-Tech Compost Spreader – “Tè Bay Tè”
Purpose: Distribute compost on mountain fields without carrying it on your back.
Construction:
You need:
1 wooden cart frame (80cm x 50cm)
2 large wooden or metal wheels
1 small trap door or hole underneath
Pulling handle or yoke
Bag of compost or dried organic material
Steps:
1. Build a box on wheels with a small door at the bottom.
2. Attach a rope to control the trap opening.
3. Pull the cart over the field and shake or open gradually.
4. Compost spreads evenly as you walk.
Can be used by one person or pulled by an animal.
---
Legal Clause
These machines are protected.
Any reproduction, adaptation, or commercialization without official Xaragua State authorization will trigger formal institutional sanctions and be considered theft of indigenous intellectual property.
---
---
SOVEREIGN STORAGE MODULES™ – GRAIN & FERTILIZER
(Extension to the Xaragua Agricultural System – XSAD-2025)
---
1. Grain Storage – “Gran Jaden” (The Grand Granary)
Purpose: Preserve dry crops (corn, millet, rice, sorghum) from humidity, rats, insects, and spoilage.
Construction:
You need:
Sun-dried bricks or compacted clay
Straw + lime plaster for sealing
Stone or cement base raised 50cm off ground
Wooden or metal door with interior latch
Roof: tin, palm leaves, or thatch
Steps:
1. Build a raised platform to prevent ground moisture.
2. Construct 4 walls using clay bricks or compacted earth.
3. Plaster inside with lime and ash (repels insects).
4. Leave a small air vent near roofline, sealed with mesh.
5. Add a sloped roof with overhang for rain protection.
Capacity: Can store up to 300–500 kg of grain per unit.
Add-on: Place basil, neem, or burnt charcoal inside for natural preservation.
---
2. Emergency Micro-Silo – “Ti Kès Sovtaj” (Rescue Box)
Purpose: Allow each family to store a 3-month supply of grain in case of disaster.
Construction:
You need:
1 large clay pot or plastic barrel
Cloth lining or waxed interior
Rope to hang or lift
Wooden cover with tight seal
Steps:
1. Dry the pot in the sun 3 days.
2. Fill with completely dry grain.
3. Add a handful of dry ashes or neem leaves.
4. Seal tightly and store in a dry, cool place.
Bonus: Portable, buried, or hidden from raiders during unrest.
---
3. Organic Fertilizer Storage – “Tè Manman” (Mother Earth Cellar)
Purpose: Store compost, ashes, dried manure or biofertilizer safely between seasons.
Construction:
You need:
Small underground pit or clay-lined box
Roof or wooden cover
Drainage trench on the side
Optional: shade with banana leaves or tarp
Steps:
1. Dig pit 1m deep near the field or house.
2. Line the inside with clay, rock, or dried banana bark.
3. Build a wooden cover and slope it to redirect rain.
4. Keep closed except during fertilization.
Result: Keeps natural fertilizer dry and usable for 6+ months.
---
Legal Note
Any commercial or unauthorized reproduction will trigger enforcement under indigenous law.
---
---
XARAGUA FERTILIZER INDEPENDENCE SYSTEM (XFIS-2025)
“The Earth Feeds the Earth.”
---
1. Classic Organic Compost – “Tè Vivan” (Living Soil)
Used to enrich soil and retain water.
Ingredients:
Dry leaves
Banana peels, rotten fruit, scraps
Manure (goat, cow, chicken)
Wood ash
Black soil / forest soil
Steps:
1. Dig a pit or make a heap in the shade.
2. Alternate dry and wet layers (e.g., leaves / manure).
3. Sprinkle with a little water and cover (straw, sack, cloth).
4. Mix every 7 days for 1 month.
Result: A black, living, rich, and free soil.
---
2. Compost Tea – “Jis Tè” (Soil Juice)
Liquid fertilizer to boost vegetables, peppers, tomatoes.
Ingredients:
1 bucket of mature compost or manure
1 bucket of water (rainwater or clean)
Cloth or fine sack
Steps:
1. Put compost into the cloth, tie like a pouch.
2. Soak in the water bucket for 3 to 5 days.
3. Stir daily, then water at the plant roots.
Fast and natural effect. Use every 10 days.
---
3. Fertilizing Ash – “Poud Lakansyèl” (Ash Rainbow)
Replaces potash, repels pests.
Ingredients:
Clean wood ash (no plastic, no commercial charcoal)
Use:
Sprinkle around plants or mix into compost.
Provides potassium + calcium + protection.
---
4. Urine-Based Fertilizer – “Dlo Gason Tè” (Sacred Nitrogen)
Very rich in nitrogen for leafy greens.
Ingredients:
Human urine (1 liter)
Water (9 liters)
Steps:
1. Dilute 1:10 with water.
2. Let it sit for 3 to 7 days.
3. Pour at the base of plants (not on leaves).
Very strong. Use once per month.
---
5. Sugar Bioferment – “Mikwob Bon Tè” (Soil Probiotic)
Activates soil microorganisms.
Ingredients:
Water (5 liters)
Molasses or brown sugar (1 cup)
Cooked rice or corn (1 handful)
Steps:
1. Mix all ingredients in a jug.
2. Seal and let ferment 5–7 days in the shade.
3. Dilute with 2 parts water and pour onto soil.
Result: Soil becomes more alive, more absorbent, less disease-prone.
---
Conclusion
With only plants, waste, water, fire, urine, sugar, and time, you can produce:
Nitrogen, potassium, phosphorus, calcium, magnesium
And beneficial microbes for 100% of your crops.
You need nothing else.
You are free.
---
